Description
1.3 Drive Manual
1.4 Operator type Pedestrian
1.5 Load capacity Q Kg 2500
Dimensions
4.4 Lift height h3 mm 115
4.19 Overall lenght l1 mm 1596
4.21 Overall width b1 mm 555
4.22 Fork dimensions - Width e mm 180
4.22 Fork dimensions - Lenght l mm 1185
4.25 Distance between fork arms b5 mm 555
4.34 Aisle width Ast mm 1851
4.35 Turning radius Wa mm 1426
Scale
Accuracy

%

0.05
Shear-beam load cells Q.ty 4
Division Kg 0.5
